We are manufacturing & exporting of a wide range of Round Vacuum Oven used by vacuum, these round vacuum ovens give heating to material.

Features:

• Temp controlled by digital temp controller cum indicator

• Vacuum chamber is wrapped with set of high quality heater for quick & uniform heating

• Door has a thick tempered toughen glass window perfectly sealed with silicon rubber gasket for observation without disturbing thermal condition

• Proper door alignment to ensure excellent vacuum performance & operate safety

• Positive screw to tighten the lid to obtain preface seal

• Fitted with vacuum valves & vacuum gauge

• Switches & indicating lamps are provided on front panel

Optional Accessories:

• PID Controller with printer option

• Programmable controller with 8 steps

• Round Vacuum Ovenis available in below Sizes:

• Size in inches Cap in LTR Cap Watts Power consumption

• 9"x12" 11 300 2 AMP

• 12"x15"26 750 3 AMP

• 18"x18"50 950 4 AMP

Product Details:

• Wall Type: Double walled

• Accuracy: +/-2 deg.C

• Inner Chamber: Stainless Steel SS 304

• Insulation: Glass Wool

• Outside Chamber: Mild steel Powder coated

• Vacuum Gauge: Upto 30 Hz

• Temperature Range: 50-200 deg. C
